Masoneilan SVI2 HART Digital Valve Positioner for Pneumatic Control

1
MOQ
US $1500.00 - 2100.00/ Unit
Price
Masoneilan SVI2 HART Digital Valve Positioner for Pneumatic Control
Features Gallery Product Description Request A Quote
Features
Specifications
Pneumatics: Air Or Sweet Natural Gas
Power Supply: 4-20mA
Connections (Supply And Actuator): 1/2" NPT
Accuracy: ± 0.5 Percent Full Span
Valve Type: Control Valve
Highlight:

Masoneilan SVI2 HART valve positioner

,

digital valve positioner pneumatic control

,

HART digital positioner control valves
Basic Infomation
Brand Name: Masoneilan
Model Number: SVI2
Document: xiangjing valve&instrument ...t .pdf
Payment & Shipping Terms
Packaging Details: Carton + Wooden Box + Protection
Delivery Time: 45-75 work days
Payment Terms: T/T
Supply Ability: 1000 units per year
Product Description
Masoneilan SVI2 Valve Controllers Customized Pneumatic Control Digital Smart HART Valve Positioner Stock
Product Attributes
Attribute Value
Pneumatics Air or Sweet Natural Gas
Power Supply 4-20mA
Connections (Supply and Actuator) 1/2" NPT
Accuracy ± 0.5 percent Full Span
Valve type Control Valve
Product Overview

The Masoneilan SVI2 is a next-generation digital valve positioner designed for precise pneumatic control in industrial automation. As part of the advanced SVI II series, this device combines HART protocol communication with customizable features to optimize valve performance. Ideal for both retrofitting existing systems and new installations, it supports single/double-acting actuators and offers stock availability for urgent requirements.

Technical Parameters
Parameter Details
Model SVI2-AP Series
Input Signal 4-20mA (HART 5/7 compatible)
Communication HART® eDDL/FDT-DTM
Accuracy ±0.5% span
Response Time <500ms
Working Temperature -40°C to +85°C
Protection IP66/IP67, NEMA 4X
Certification ATEX, FM, IECEx, CSA
Supply Pressure 20-150 psi (1.4-10.3 bar)
Air Consumption 0.1 SCFM (steady-state)
Installation Direct/bracket mount
Housing Material Aluminum (optional stainless)
Key Features
  • HART 7 Compatibility: Bidirectional digital communication for remote configuration
  • Custom Pneumatic Control: Adaptive PID tuning for single/double-acting actuators
  • Auto-Calibration: One-touch AutoTune function for rapid commissioning
  • Non-Contact Sensor: Magnetic position detection for maintenance-free operation
  • Explosion-Proof Design: ATEX/IECEx certified for hazardous environments
  • Low Air Consumption: Energy-efficient design reduces operational costs
  • Multi-Language Display: Local LCD with push-button interface (optional)
Applications
Oil & Gas: Refinery distillation and pipeline ESD systems Power Generation: Steam turbine bypass and boiler feedwater control Chemical Plants: Reactor pressure regulation and batch processing Water Treatment: Municipal water supply and wastewater treatment Pharmaceutical: Sterile environment valve automation Marine: Shipboard HVAC and cargo handling systems
