SVI II AP (Smart Valve Interface, Advanced Performance) is an advanced digital valve positioner that boasts a 32-bit microprocessor and a local interface capable of controlling a pneumatic actuator with a 2-wire 4-20mA control signal. The device also offers bi-directional communication functionalities with the use of the HART protocol.
This instrument is designed to be universal, making it easy to retrofit into existing analog positioners that are currently in use on both Masoneilan and non-Masoneilan pneumatic actuators, whether they are single or double acting.
This advanced technology offers a comprehensive solution for modern valve position sensing needs, combining simplicity, accuracy, and reliability in one adaptable system.
Overall, this non-contact position sensing technology provides a long-lasting, reliable, and user-friendly solution for valve position sensing requirements.
| Brand Name: | Masoneilan |
| Product Name: | Smart Valve Positioner |
| Valve Position Automation: | Yes |
| Repeatability: | +/- 0.3 Percent Full Span |
| Linearity: | +/- 1 Percent Full Scale |
| Operating Temperature: | -50°C To +85°C |
| Diagnostics: | Standard Diagnostics, Advanced Diagnostics |
| Pneumatics Action: | Single Or Double Acting, Fail Safe, Rotary And Linear |
| Air Delivery: | 280 SLPM @ 30psi |
| Minimum Current Signal: | 3.2 MA |
| Air Supply Pressure: | Single-Acting(1.4 To 6.9 Bar), Double-Acting(1.4 To 10.3 Bar) |
| Hysteresis + DeadBand: | +/- 0.3 Percent Full Span |
