Auto Calibration Aluminum Control Valve Positioner 3.6 - 300 Mm Valve Travel

Auto Calibration Aluminum Control Valve Positioner 3.6 - 300 Mm Valve Travel

digital valve positioner

smart valve positioner

Place of Origin:


Brand Name:




Model Number:

YT 3350

Contact Us

Request A Quote
Product Details
Set Point:
4 To 20 MA
Valve Travel:
3.6 To 300 Mm
Opening Angle:
24 To 100°
Product Description

Rotork smart Digital Valve Positioner YT-3300 single acting positioner for control valve

Product Introduction

YT-3300 / 3350 / 3303 / 3301 series Smart Valve Positioner accurately controls valve stroke in response to an input signal of 4~20mA from the controller. Built-in micro-processor optimizes the positioner’s performance and provides unique functions such as Auto-Calibration, PID Control, and HART Protocol Communications.

Quick Details

Place of Origin Korea
Brand Name YTC
Model Number YT-3350
Diagnostics 5 Pressure Sensors
Materials Case/Cover: - Aluminum ASTM 360
Welded BW or SW
Operating Temperature Standard Temperature
Screwed NPT 1/4" through 2" (20 through 50 mm)
Body Materials Cast iron PFA lined
Actuators Model 35 spring-opposed rolling diaphragm
Trim Eccentric rotary plug
inherent Characteristics Linear


➢ LCD display enables users to monitor the positioner status.

➢ Users will easily understand the method of using 4 buttons because it works the same in all versions of firmware interfaces.

➢ When an unexpected situation like momentary blackout happens, our positioner boot-time only takes 0.5 seconds and this can minimize the travel of the valve which consequentially increases the safety of the system.

➢ Positioner operates normally even there are sudden changes in supply pressure and / or high vibration environment.

➢ YT-3301 remote positioner is stronger on a high temperature and vibration environment because it is separated into a remote sensor and positioner.

➢ The method of Auto Calibration is very simple.

➢ As an advantage of having very low air consumption, It could greatly reduce operating costs in large-scale plants.

➢ It is compatible with most of the controllers.

➢ Orifices can be installed even in the field to minimize the hunting occurrence and optimize operating conditions.

➢ Various information about positioner can be processed by HART communication (HART option)

➢ The valve system becomes more stable by outputting analog feedback signal. ➢ Different valve characteristics can be adjusted – Linear, Quick-Open, Equal Percentage, and User Set which users can make 5 or 18 points characterizations.

➢ Tight Shut – Close and Shut - Open can be set.

➢ PID parameters can be adjusted in the field without any additional communicator.

➢ A/M switch can be used to direct supply air to the actuator or to manually operate the positioner or valve without any signal.

➢ Split range 4~12mA or 12~20mA can be set.

➢ The operating temperature for remote sensor of YT-3301 is -40 ~ 120℃. Operating temperature for positioners is -30 ~ 85℃ or -40 ~ 85℃ (Please check the certified explosion-proof temperature)

➢ The hand calibration function can set Zero point or Endpoint manually.

➢ It has an IP66, Type 4X(FM) protection grade.

➢ Polyester powder coating resists the corrosion process. (except YT-3350).




Auto Calibration Aluminum Control Valve Positioner 3.6 - 300 Mm Valve Travel 0


Detailed Image

Auto Calibration Aluminum Control Valve Positioner 3.6 - 300 Mm Valve Travel 1

Auto Calibration Aluminum Control Valve Positioner 3.6 - 300 Mm Valve Travel 2
