| MOQ: | 1 Set/Sets |
| Price: | Negotiation |
| Standard Packaging: | One Robot robotic arm 6 axis KR 60-3 robot spray painting and industrial robotic arm price packing with fumigation wooden frame, WG:700KG Controller and other parts packing with brown box, WG:80KG Total WG:780KG(>VG) |
| Supply Capacity: | 10 Set/Sets per Month |
Robot spray painting 6 axis 60 Kg robotic arm and industrial robotic arm price
Main Specifications:
Max.reach:2,033 mm
Rated payload:60 kg
Pose repeatability:±0.06mm
Numberof axes:6
Mounting position:Floor
Robot footprint:850 mm x 950 mm
Weight: (excluding controller), approx. 665 kg
Controller:KR C4
More products:
KUKA robot
1: KR 6 R1820 6KG 6axis welding robot
2: KR 6 R700 sixx 6 axis payload 6kg multifunctional industrial robot
3: KR 10 R1420 6 aixs 10kg welding robot
4: KR 210 R2700 EXTRA 210KG payload multifunctional industrial robot
ABB robot
1: IRB 1200/7/0.7 6 axis 7kg payload multifunctional industrial robot
2: IRB 1520ID 6 axis 5kg payload for welding
3: IRB 6700/150/3.2 150 kg payload for handing,cutting and palletizing
Collaborative robot
1: Collaborative robot of Chinese industrial robot arm 6 axis 6kg paylad
2: Collaborative robot of chinese industrial robot arm 7 axis 5kg payload
| Product name | Robot spray painting 6 axis 60 Kg robotic arm and industrial robotic arm price | |
| Application | Robot spray painting; robotic arm ;industrial robotic arm price | |
| Model | KR 60-3 F | |
| Max.reach | 2,033 mm | |
| Rated payload | 60 kg | |
| Rated suppl. load, arm/link arm/rot. column | 35 kg/–/– | |
| Rated total load | 95 kg | |
| Pose repeatability | ±0.06mm | |
| Numberof axes | 6 | |
| Mounting position | Floor | |
| Variant | – | |
| Robot footprint | 850 mm x 950 mm | |
| Weight (excluding controller), approx. | 665 kg | |
| Axis data / | Speed with rated | |
| Range of motion | payload 30kg | |
| Axis 1 (A1) | +/-185° | 140°/s |
| Axis 2 (A2) | +35°/-135° | 126°/s |
| Axis 3 (A3) | +158°/-120° | 140°/s |
| Axis 4 (A4) | +/-350° | 260°/s |
| Axis 5 (A5) | +/-119° | 245°/s |
| Axis 6 (A6) | +/-350° | 322°/s |
| Operating conditions | ||
| Ambient temperature | +10°C to +55°C | |
| Protection rating | ||
| Protectionrating, robot | IP 64 | |
| Protection rating, in-line wrist | IP 64 | |
| Controller | KR C4 | |
| Teach pendant | KUKA smartPAD | |
1. Swift delivery
For common parts, we can deliver the goods within 3 days
2. Original products
All the products we sell are from origin manufacturer. We will submit all the manufacturer documentation while we finish delivery.
3. Quality Assurance
4. Technical Support
Including inspection,repair and maintenance, we can give all kinds of technical support.
5. Quickly responce
Our staffs will keep 24h online and answer your question very quickly.
|
|
