China robot industrial M-10 iD 8L pallet stacking robots payload 8kg robotic arm

China robot industrial M-10 iD 8L pallet stacking robots payload 8kg robotic arm

MOQ: 1 Set/Sets
Price: Negotiation
Standard Packaging: Regular packing ,100% Factory Sealed. China robot industrial M-10 iD 8L handing robotic arm 8kg payload robot for palletizing
Supply Capacity: 100 Set/Sets per Month
Detail Information
Place of Origin
Japan
Brand Name
FANUC
Applicable Industries:
Retail, Construction Works , Food & Beverage Shops
Condition:
New
After-sales Service Provided:
Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Video Technical Support, Online Support
Product Name:
Industrial M-10 ID 10L Handing Robotic Arm Palletizer Robot
Number Of Axes:
6
Maximum Reach:
2032mm
Max Payload:
8 Kg
Pose Repeatability(ISO 9283):
±0.03mm
Mount Position:
Floor Upside-down Angle Mount
Weight:
Approx. 180 Kg (without Controller)
Protection Rating:
IP54
Type:
Articulated Type
Drive Method:
Electric Servo Drive By AC Servo Motor
Port:
Shanghai
Minimum Order Quantity:
1 Set/Sets
Price:
Negotiation
Packaging Details:
Regular packing ,100% Factory Sealed. China robot industrial M-10 iD 8L handing robotic arm 8kg payload robot for palletizing
Supply Ability:
100 Set/Sets per Month
High Light:

fanuc material handling robot

,

delta robot arm

Product Description
Product Description

China robot industrial M-10 iD 8L handing robotic arm 8kg payload robot for palletizing

The new M-10iD/8L robot reaches the highest axis speed and precision in its class. Especially for narrow work spaces, or when being mounted upside down, this highly versatile robot gives a full working envelope, reach and stroke for higher production throughput.

Product name
China robot industrial M-10 iD 8L handing robotic arm 8kg payload robot for palletizing
Controlled axes
6
Max. payload at wrist
8kg
Repeatability
±0.03mm
Reach
2032mm
Mass (without controller)
180kg
Drive method
Electric servo drive by AC servo motor
Installation
Floor Inverted, Angle
Matching controller / Input power capacity
FANUC R-30iB Controller

FANUC R-30iB Mate Cabinet Controller

FANUC R-30iB iPendant Touch Controller

FANUC R-30iB A-Cabinet Controller

FANUC R-30iB B-Cabinet Controller
                                                                              Robot Motion Speed
J1
260 °/s (4.54 rad/s)
J2
280 °/s (4.89 rad/s)
J3
315 °/s (5.5 rads/s)
J4
 430°/s (7.5 rad/s)
J5
430°/s (7.5 rad/s)
J6
630 °/s (11 rad/s)
                                                                            Robot Motion Range
J1
+340°-360°
J2
±250°
J3
±290°
J4
±380°
J5
±380°
J6
±720°
Application
Palletizing, Assembly, Machine Loading, Machine Tending, Milling, Part Transfer

Main Features

1. the FANUC M-10iD has a short, standard, and long arm available, and two different types of wrists, hollow or high-inertia. The hollow wrist, dress-out and the routing of cables simplifies the robot, improves the reliability, and reduces the overall system cost. Also, the M-10iD robot can be mounted at any angle on the floor, wall, or ceiling. The work envelope is also increased as J3 can flip over backwards.


2. Whether new or used, the FANUC M-10iD is the perfect solution for your application as it sets the industry standards for small robots with its high axis speeds and incredible repeatability for it's class. The M-10iD is built with precision and speed in mind as it has increased acceleration performance that results in higher productivity.
