| MOQ: | 1 Set/Sets |
| Price: | Negotiation |
| Standard Packaging: | Hot selling industrial 6 axes robotic arm robot kit M-10iA/12S pick and place robot Export using plywood large wooden box Length: 70cm Width: 50cm Height: 100cm Weight 15KG |
| Supply Capacity: | 100 Set/Sets per Month |
The new M-10iD/12 robot reaches the highest axis speed and precision in its class. Especially for narrow work spaces, or when being mounted upside down, this highly versatile robot gives a full working envelope, reach and stroke for higher production throughput.
|
Product name
|
China 6-axes welding robot Price cnc robot M10 iD 12 1.44m reach handing robot
|
|
Controlled axes
|
6
|
|
Max. payload at wrist
|
12kg
|
|
Repeatability
|
±0.08mm
|
|
Reach
|
1441mm
|
|
Mass (without controller)
|
130kg
|
|
Drive method
|
Electric servo drive by AC servo motor
|
|
Installation
|
Floor Inverted, Angle
|
|
Matching controller / Input power capacity
|
FANUC R-30iB Controller
FANUC R-30iB Mate Cabinet Controller FANUC R-30iB iPendant Touch Controller FANUC R-30iB A-Cabinet Controller FANUC R-30iB B-Cabinet Controller |
|
Robot Motion Speed
|
|
|
J1
|
260 °/s (4.54 rad/s)
|
|
J2
|
280 °/s (4.89 rad/s)
|
|
J3
|
315 °/s (5.5 rads/s)
|
|
J4
|
430°/s (7.5 rad/s)
|
|
J5
|
430°/s (7.5 rad/s)
|
|
J6
|
630 °/s (11 rad/s)
|
|
Robot Motion Range
|
|
|
J1
|
+340°-360°
|
|
J2
|
±250°
|
|
J3
|
±290°
|
|
J4
|
±380°
|
|
J5
|
±380°
|
|
J6
|
±720°
|
|
Application
|
Palletizing, Assembly, Machine Loading, Machine Tending, Milling, Part Transfer
|
1. the FANUC M-10iD has a short, standard, and long arm available, and two different types of wrists, hollow or high-inertia. The hollow wrist, dress-out and the routing of cables simplifies the robot, improves the reliability, and reduces the overall system cost. Also, the M-10iD robot can be mounted at any angle on the floor, wall, or ceiling. The work envelope is also increased as J3 can flip over backwards.
2. Whether new or used, the FANUC M-10iD is the perfect solution for your application as it sets the industry standards for small robots with its high axis speeds and incredible repeatability for it's class. The M-10iD is built with precision and speed in mind as it has increased acceleration performance that results in higher productivity.
.
