Chinese brand DH-ROBOTICS clamping device match with collaborative robot arm

one set
MOQ
Chinese brand DH-ROBOTICS clamping device match with collaborative robot arm
Features Gallery Product Description Request A Quote
Features
Specifications
Stroke (adjustable): 106/122 Mm
Position Resolution (fingertip): ±0.05 Mm
Gripper Mass: 1-2 Kg
Grip Force (adjustable): 10-65 N
Friction Grip Payload: 1.68 Kg
Form-fit Grip Payload: 1.68 Kg
Nominal Supply Voltage: 24VDC±10%
Full-stroke Closing Time: 0.7 S
Communication Protocol: TCP/IP,USB2.0, RS485,I/O
Highlight:

122mm Stroke Robotic Clamp Device

,

24VDC Robotic Clamp Device

,

65N Grip Robotic Clamp Device

Basic Infomation
Place of Origin: Chinese
Brand Name: DH-ROBOTICS
Certification: CE CO
Model Number: DH-3
Payment & Shipping Terms
Packaging Details: cartons
Delivery Time: 15 working days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 999 sets /month
Product Description





Chinese brand DH-ROBOTICS clamping device match with collaborative robot arm



Detailed Images
Production Name Chinese brand DH-ROBOTICS clamp device DH-3 matched with collaborative robot arm
Model DH-3 robotic clamp device
Application robotic clamp device
Stroke (adjustable) 106/122 mm
Form-fit grip payload 1-2 kg
Friction grip payload 1.68 kg
Grip force (adjustable) 10-65 N
Gripper mass 1.68 kg
Position resolution (fingertip) ±0.05 mm
Nominal supply voltage 24VDC±10%
Full-stroke closing time 0.7 S
Communication protocol TCP/IP,USB2.0, RS485,I/O

Chinese brand DH-ROBOTICS clamping device match with collaborative robot arm 0Chinese brand DH-ROBOTICS clamping device match with collaborative robot arm 1Chinese brand DH-ROBOTICS clamping device match with collaborative robot arm 2Chinese brand DH-ROBOTICS clamping device match with collaborative robot arm 3Chinese brand DH-ROBOTICS clamping device match with collaborative robot arm 4





Chinese brand DH-ROBOTICS clamping device match with collaborative robot arm 5







Chinese brand DH-ROBOTICS clamping device match with collaborative robot arm 6                                                                            Chinese brand DH-ROBOTICS clamping device match with collaborative robot arm 7
