ABB IRB6700 6 Axis Industrial Robot Arm Assembly Polishing Picking Welding Robot And Payload 155Kg Reach 2850mm

Basic Information
Place of Origin: China
Brand Name: ABB
Model Number: IRB6700-155/2.85
Minimum Order Quantity: 1 set
Price: US $31497.00 - 40495.00/ Set
Packaging Details: ONE ABB large industrial total station robotic 6 axis ABB IRB6700 6 Axis Industrial Robot Arm Assembly Polishing Picking Welding Robot and Payload 155Kg Reach 2850mm packing with fumigation wooden frame, Total WG:1700KG(>VG)
Delivery Time: 30-60 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 sets/Month
Name: ABB IRB6700 6 Axis Industrial Robot Arm Assembly Polishing Picking Welding Robot And Payload 155Kg Reach 2850mm Application: Assembly/ Polishing/ Picking/ Welding
Payload: 155Kg Reach: 2850mm
Number Of Axes: 6 Material: Aluminium Alloy
Protection: Std:IP67. Mounting: Floor, Inverted
Position Repeatability: 0.10mm Controller: IRC5 Single Cabinet/ IRC5 PMC Panel Mounted Controller
High Light:

Reach 2850mm ABB Robot Arm

,

Inverted Mounting ABB Robot Arm

,

IP67 Welding ABB Robot Arm

ABB IRB6700 6 Axis Industrial Robot Arm Assembly Polishing Picking Welding Robot and Payload 155Kg Reach 2850mm

ABB IRB6700 6 Axis Industrial Robot Arm Assembly Polishing Picking Welding Robot And Payload 155Kg Reach 2850mm 0ABB IRB6700 6 Axis Industrial Robot Arm Assembly Polishing Picking Welding Robot And Payload 155Kg Reach 2850mm 1ABB IRB6700 6 Axis Industrial Robot Arm Assembly Polishing Picking Welding Robot And Payload 155Kg Reach 2850mm 2ABB IRB6700 6 Axis Industrial Robot Arm Assembly Polishing Picking Welding Robot And Payload 155Kg Reach 2850mm 3

Specification

Robot version Reach(m) Handling capacity(kg) Center of gravity(kg) Wrist torque(Nm)
Without LeanID
IRB 6700-200/2.60 2.60 200 300 981
IRB 6700-155/2.85 2.85 155 300 927
IRB 6700-150/3.20 3.20 150 300 1135
IRB 6700-300/2.70 2.70 300 300 1825
Without LeanID
IRB 6700-200/2.60 2.60 175 300 981
IRB 6700-155/2.85 2.85 140 300 927
IRB 6700-150/3.20 3.20 145 300 1135
IRB 6700-300/2.70 2.70 270 300 1825
Number of axes 6
Protection Std:IP67.Option:Foundry Plus 2
Mounting Floor,inverted
Controller

IRC5 Single Cabinet/

IRC5 PMC Panel Mounted Controller



Performance(according to ISO 9283)



Position repeatability

Path repeatability

IRB 6700-200/2.60 0.05mm 0.10mm
IRB 6700-155/2.85 0.10mm 0.15mm
IRB 6700-150/3.20 0.10mm 0.15mm
IRB 6700-300/2.70 0.10mm 0.15mm

Technical information

Electrical Connections
Supply voltage 200-600 V,50/60 Hz
Energy consumption 2.8KW
Physical
Robot base 1004x720 mm
Robot weight(without Dress Pack)
IRB 6700-200/2.60 1250kg
IRB 6700-155/2.85 1260kg
IRB 6700-150/3.20 1280kg
IRB 6700-300/2.70 1525kg
