GP180 6 Axis Robot Arm For Material Handing Payload 180kg Reach 2702mm Fast And Accurate Material Handing Robot

GP180 6 Axis Robot Arm For Material Handing Payload 180kg Reach 2702mm Fast And Accurate Material Handing Robot

Payload 180kg Yaskawa Robot Arm

Reach 2702mm Yaskawa Robot Arm

6 Axis Yaskawa Robot Arm

Place of Origin:

China

Brand Name:

YASKAWA

Model Number:

GP180

Contact Us

Request A Quote
Product Details
Controlled Axes:
6
Maximum Payload:
180kg
Repeatability:
±0.2
Horizontal Reach:
2702mm
Vertical Reach:
3393mm
Weight:
1020kg
Lnternal User LO Cable:
24 Conductors W/ Ground
Lnternal User Air Line:
(1) 3/8" Connection
Power Requirements:
380-480 VAC
Power Rating:
5 KVA
Contoller:
YRC1000
Product Description

GP180 6 Axis Robot arm for Material Handing Payload 180kg Reach 2702mm Fast and Accurate Material Handing Robot



Key Benefits

High payload for heavy part processing

Engineered for easy installation,operation and maintenance

Single robot-to-controller cable connection enables fast setup



Applications

Material Handling
Machine Tending
Press Tending



Options
· Robot risers and base plates
· PLC integration via MLX300 software option*
· Extended length manipulator cables
· Wide variety of fieldbus cards
· Functional Safety Unit (FSU)
· External axes



·Increase productivity with the powerful and efficient GP180 robot.

·180-kg payload capacity and wide working envelope provide superior performance for handling applications.
·Exceptionally fast axis speeds and acceleration capabilities reduce cycle time and increase production output.
·Streamlined upper arm allows easy access to parts in tight spots and avoids potential interference with fixtures, improving application flexibility.
·Wide wrist motion range eliminates interference and improves application flexibility.
·Reduced interference design allows close proximity placement of robots for high-density workcells.
·High moment and inertia ratings allow handling of larger and heavier payloads.

·Cable installation tube facilitates fieldbus routing through the S-axis.

·Single power and control cable reduces wiring time and increases work efficiency.
·New robot harness design for improved diagnostics and maintenance.
·Home position data can be saved without battery connection for easy maintenance.
·The GP180 has an IP67-rated wrist and an IP54 body standard. An XP (eXtra Protection) package that increases the body protecuon rating to IP65 is available.
·The GP180 can be floor-mounted. Brakes are included on all axes.
·Pre-wired for servo gripper which allows a wider range of product handling.
·Compact YRC controller utilizes the lightweight standard teach pendant with intuitive programming.
