| Place of Origin: | China |
|---|---|
| Brand Name: | NEOTECHA |
| Model Number: | SNB/SNC |
| Minimum Order Quantity: | 1 set |
| Delivery Time: | 4-8 work days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 999 |
| Model: | SNB/SNC | Certifications: | CRN, CUTR, PED, CE, Fugitive Emission |
|---|---|---|---|
| End Connection: | Wafer | Body Design: | Short Pattern |
| Material: | Teflon, 316 Stainless Steel | Operating Temperature: | Less Than 200 C |
| Pressure Class: | PN | Valve Size Standard: | DN |
| Valve Type: | Ball Valve | Media: | Aggressive Liquids/Gases |
| High Light: | Wafer End PFA Lined Valves,Short Pattern PFA Lined Valves,Aggressive Liquids PFA Lined Valves |
||
Neotecha Model SNB/SNC PFA Lined Ball Valves Temperature Less Than 200 C
Specifications
Certifications:CRN, CUTR, PED, CE, Fugitive Emission
End Connection:Wafer
Body Design:Short Pattern
Material:Teflon, 316 Stainless Steel
Operating Temperature:Less Than 200 C
Pressure Class:PN
Seat/Seal Type:Ball
Valve Size Standard:DN
Valve Type:Ball Valve
Media:Aggressive Liquids/Gases
Features
PFA lining offers highest corrosion resistance
The smooth external surface of the investment cast Stainless Steel body makes the valve an ideal selection for high integrity installations
Short face to face dimensions allow easy installation
Bubble tight shut-off: precision machined ball and seats guarantee an absolute leak-free valve
Full bore offers high Kv-value equal to the pipe
One piece ball/stem: protects the integrity of the PFA ball lining, no hysteresis, ideal for flow control applications
Anti blow-out shaft design, which can not be affected by the media, according API 609
Static electricity: any build-up of static electricity is eliminated since the ball/stem and the housing are of the same potential
Constant torque: the unique two-piece body construction together with the spring loaded seats guarantee a constant torque even after months of operation
The self adjusting packing is maintenance free and provides a leak free stem seal which is TA-Luft VDI 2440 approved
The C ball version is dead space free and allows easy cleaning in line
Direct mounting according to ISO 5211
Company Profile
Xiangjing(Shanghai) Mechnical Electrical Tech. Co., Ltd is is the subcompany of Dr. Industry Group Co., Ltd, was founded in January 2015, We focus on discrete industrial automation and process industrial automation, and we can design, develop, install, testing, debug industrial robot, its units and related accessories including fixture, transmission device, positioning device and control system, we can provide Welding Robot, Spray Painting Robot, Transfer Robot, and Grinding Robot, we have many reference in automation industry in China. Meanwhile we are agent of KUKA , ABB, Yaskawa industrial robots, and distributor of FUNC industrial robot. we are the important partner of them in the China market, we have more than 7 engineers with rich expericence, who had been worked for ABB or KUKA more than 10 years. meanwhile Dr. Industry Group can provide ABB and KUKA robot training for our customer, there are weeekly training courses. In the process of industrial automation field, Xiangjing can provide control valve, actuator, postioner, and regulator, Xiangjing is the improtant partner of Emerson process management in the China market, we are fisher and rosemount project authorized agent in China, we can provide fisher control valve, fisher regulator, rosemount pressure, level, thermal transimtter, rosemount wireless instrument, Daniel Flowmeter, ASCO Solenoid Valve, TopWorx Switch and so on. We have many references on power, chemical industry in China. Xiangjing has two teams, one is for discrete industrial automation and the other is for process industrial automation with rich experience, we are good partner of you.
