Name: Kuka Pallet Industrial Robot Arm 6 Axis KR 240 R3330 Payload Of 240Kg Palletizer Robot With Gripper Smart Robot
Brand: KUKA
SKU: KR 240 R3330
Rating: 4.7 (152 reviews)

Home > products > Kuka Robot Arm >

Kuka Pallet Industrial Robot Arm 6 Axis KR 240 R3330 Payload Of 240Kg Palletizer Robot With Gripper Smart Robot

Kuka Pallet Industrial Robot Arm

240Kg Payload Industrial Robot Arm

3326mm Reach Industrial Robot Arm

Place of Origin:

CHINA

Brand Name:

KUKA

Certification:

Model Number:

KR 240 R3330

Request A Quote

Product Details

Type:

KR 240 R3330

Maximum Reach:

3326 Mm

Maximum Payload:

297 Kg

Rated Payload:

240 Kg

Pose Repeatability (ISO 9283):

± 0.08 Mm

Number Of Axes:

Footprint:

1050 Mm X 1050 Mm

Weight:

Approx. 2421 Kg

Controller:

KR C4

Teach Pendant:

KUKA SmartPAD

Industrial 6 Axis Robotic Arm Painting Yaskawa MPX2600 With CNGBS Gun Cleaning Station

Get Best Price

7 Axis Kuka Robotic Arm LBR Iiwa 7 R800 With CNGBS Robot Gripper For Handling As Collaborative Robots

Get Best Price

VL Series Vertical Machining Center V850L Used In Various Production Sites As Machine Tools Accessories

Get Best Price

KR 70 R2100 Industrial KUKA Robot 6 Axis Manipulator For Other Welding Machine

Get Best Price

86-151-2102-3088

edward.zhao@gongboshi.com

Contact Now

Product Description

Kuka pallet industrial robot arm 6 axis KR 240 R3330 payload of 240 kg palletizer robot with gripper smart robot

The KR 240 R3330 is designed for a rated payload of 240 kg in order to optimize the dynamic performance of the robot. With reduced load center distances, higher loads up to the maximum payload may be used. The specific load case must be verified using KUKA.Load. For further consul tation, please contact KUKA Support.

Specification

item	value
Applicable Industries	Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, Other
After Warranty Service	Online support
Name	Kuka pallet industrial robot arm 6 axis KR 240 R3330 payload of 240 kg palletizer robot with gripper smart robot
Showroom Location	None
Video outgoing-inspection	Provided
Machinery Test Report	Provided
Marketing Type	New Product 2020
Warranty of core components	1 Year
Core Components	PLC
Condition	New
Place of Origin	China
	Shanghai
Brand Name	KUKA
Weight	2421kg
Dimension(LWH)	After negotiations
Power	380V
Certification	CE
Warranty	1 Year
	Online support
Weight (KG)	2421kg
Maximum reach	3326 mm
Maximum payload	297 kg
Rated payload	240 kg
Pose repeatability (ISO 9283)	± 0.08 mm
Number of axes	6
Mounting position	Floor
Footprint	1050 mm x 1050 mm
Weight	approx. 2421 kg
Ambient temperature during operation	10 °C to 55 °C (283 K to 328 K)
Controller	KR C4

Packing & Delivery

ONE Kuka pallet industrial robot arm 6 axis KR 240 R3330 payload of 240 kg palletizer robot with gripper smart robot packing with fumigation wooden frame, WG:2421 kg

Company Profile

Xiangjing(Shanghai) Mechnical Electrical Tech. Co., Ltd is is the subcompany of Dr. Industry Group Co., Ltd, was founded in January 2015, We focus on discrete industrial automation and process industrial automation, and we can design, develop, install, testing, debug industrial robot, its units and related accessories including fixture, transmission device, positioning device and control system, we can provide Welding Robot, Spray Painting Robot, Transfer Robot, and Grinding Robot, we have many reference in automation industry in China. Meanwhile we are agent of KUKA , ABB, Yaskawa industrial robots, and distributor of FUNC industrial robot. we are the important partner of them in the China market, we have more than 7 engineers with rich expericence, who had been worked for ABB or KUKA more than 10 years. meanwhile Dr. Industry Group can provide ABB and KUKA robot training for our customer, there are weeekly training courses. In the process of industrial automation field, Xiangjing can provide control valve, actuator, postioner, and regulator, Xiangjing is the improtant partner of Emerson process management in the China market, we are fisher and rosemount project authorized agent in China, we can provide fisher control valve, fisher regulator, rosemount pressure, level, thermal transimtter, rosemount wireless instrument, Daniel Flowmeter, ASCO Solenoid Valve, TopWorx Switch and so on. We have many references on power, chemical industry in China. Xiangjing has two teams, one is for discrete industrial automation and the other is for process industrial automation with rich experience, we are good partner of you.

FAQ

1. who are we?
We are based in Shanghai, China, start from 2015,sell to South America(40.00%),Southeast Asia(30.00%),Eastern Europe(20.00%),Western Europe(5.00%),Domestic Market(5.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Robot,Control Valve

4. why should you buy from us not from other suppliers?
1: We are with ABB,KUKA,FANUC,YASKAWA agentand many other brands agent for years. 2: Majority of our engineer from KUKA, ABB. The engineering manager worked in ABB company for 19 years. 3: We can offer majority of industrial controlled component.

5. what services can we provide?
Accepted Delivery Terms: FOB,EXW；
Accepted Payment Currency:USD;
Accepted Payment Type: T/T,Western Union;
Language Spoken:English,Chinese

Production Name	Industry Robot
Power supply	20 ~ 25V
Protection rating	IP54
Weight	1.25kg

FAQ

Q.How Long will You Need before Delivery? A:We have many common models in stock, so that wecan deliver the goods very soon(less than 3 days).

Q.What is Your Payment Term?

A:Normally T/T 30% in advance, balance to be paidbefore delivery, We also support the trade assurance,OlA.

Q:What is Trade Assurance? A:Trade Assurance is a free service by Alibaba.comthat's designed to help create trust between buyers andsuppliers.Trade Assurance helps buyers in the event ofshipping and quality-related dispute.

Q:Does Trade Assurance Charge Fees? A:No.Trade Assurance is free for both buyers andsuppliers.

Q:What Kind of Trade Terms Can You Do?

A:EX-WORKS,FOB,CFR,CIF,etc.
