Spirax Sarco SP7-10 SP7-11 SP7-12 Smart Valve Positioners With EZ Control Valve

Spirax Sarco SP7-10 SP7-11 SP7-12 Smart Valve Positioners With EZ Control Valve

Spirax Sarco Control Valve Positioner

SP7-12 Smart Valve Positioner

Intelligent Valve Positioner SP7-11

Brand Name:

spirax sarco

Model Number:

SP7-10, SP7-11

Contact Us

Request A Quote
Product Details
Model:
Spirax Sarco SP7-10, SP7-11 And SP7-12 Smart Valve Positioners With EZ Control Valve
Connection Type:
2 Wire
Output Signal:
4 ~ 20 MA DC
Brand:
Spirax Sarco
Bus/Sensor:
4-20 MA Transmitter
Area Classification:
Class 1, Div. 1, Groups A,B,C&D;
Visual Display:
90° Green Open / Red Closed
Shaft:
NAMUR, 304 Stainless Steel
Conduit Entries:
(2) 1/2" NPT
O-rings:
Silicone
Product Description
Product Description






spirax sarco SP7-10, SP7-11 and SP7-12 Smart valve Positioners with EZ control valv



The SP7-1* smart positioner can control any valve that is actuated by a linear or rotary pneumatic actuator that conforms with NAMUR. It guarantees an exact proportionality between the stroke of the valve and the value of the electrical input signal (mA) into the positioner. The SP7-1* has a cast aluminium housing that is also treated for outdoor installation. The unit can be mounted onto pneumatic actuators either rotary -57 to 57° or linear -28 to 28°. The positioner can be supplied without a mounting kit or with a kit for rotary or linear actuators, the type must be specified when ordering. The positioner can be supplied without a pressure gauge block or with a pressure gauge block, the type must be specified when ordering.

The positioner is supplied for a control signal in mA and for an air supply pressure from 1.4 to 6 bar. The SP7-1* positioner can also be used to reverse the action of the control signal. The positioner has a local communication interface (LCI) as standard in the SP7-10. Additionally, a ‘HART® communication’ option for communication via the 20 mA signal is available. Both communications are based on the HART® Protocol. Alternatively, HART®5 or HART®7 are available. Other available options are the SP7-11 with a PROFIBUS PA module or the SP7-12 with FOUNDATION Fieldbus module. In addition to its input for the analog position set point, the positioner is equipped with a digital input which can be used to activate control system functions in the device. A digital output allows you to output collective messages (alarms/faults). Note: Throughout the document SP7-1* is written where the information is relevant to all versions; the SP7-10, SP7-11 and SP7-12. Where the information is specific it will be referenced as the version appropriate




Specifications


Pressure Range

5-100 psi (35-700 kPa), (0.35-7 bar)

Certifications

PED, CUTR, ATEX

Inlet Pressure Rating

210 psi (1.5 MPa, 15 bar) maximum

Operating Temperature

Standard Temperature

Connection

SOLENOID

Application

Gas& Oil industry



Spirax Sarco SP7-10 SP7-11 SP7-12 Smart Valve Positioners With EZ Control Valve 0






Special features


This test requires the EDP300 Pressure Sensor Module Option.
The Valve Signature, which is displayed via the DTM, is used to
detect the static and sliding friction of the valve. The valve
hysteresis is also displayed, for this purpose the various
positions across the entire valve range are approached in steps.
When the Valve Signature starts, the entire valve operating range
for the ‘open and closed directions’ is covered in an uncontrolled
manner (open loop test). During this process, the pressure
patterns of the diagnostic pressure sensors are recorded using a
configurable number of 10 to 100 positions.
For each step, there is a 4-second delay so that the valve can set
itself after the required position has been reached.
Once the signature test is complete the parameters selected by
the user are loaded from the device and displayed.
Consequently, excessively heavy movement of the valve is
displayed as a greater hysteresis.
Additionally, the position and signal waveform for the optional
Universal Input can also be recorded.
The Valve Signature of a new or refurbished assembly provides
valuable data as the baseline performance for comparison of
valve and actuator condition as part of routine valve
performance verification.




Detailed Images


Spirax Sarco SP7-10 SP7-11 SP7-12 Smart Valve Positioners With EZ Control Valve 1

Packing & Delivery


Spirax Sarco SP7-10 SP7-11 SP7-12 Smart Valve Positioners With EZ Control Valve 2

Our Service


Spirax Sarco SP7-10 SP7-11 SP7-12 Smart Valve Positioners With EZ Control Valve 3

1.Swift delivery
For common parts, we can deliver the goods within 3 days

2.Original products
All the products we sell are from origin manufacturer. We will submit all the manufacturer documentation while we finish delivery.

3.Quality Assurance

4.Technical Support
Including inspection,repair and maintenance, we can give all kinds of technical support.

5.Quickly responce
Our staffs will keep 24h online and answer your question very quickly.
