FEATURES:
1. The upper loading integrated structure is adopted, with reduced number of flange couplings and high reliability.
2. The valve has a simple structure and is easy to repair.
3. The ball valve adopts three or four floating valve seats and a fixed ball.
4. The design includes the fire protection structure, the structure capable of preventing the valve stem from being blown out,
the scraper structure and the dust prevention structure.
5. The valve is characterized by wear resistance and erosion resistance.
SPECIFICATIONS:
Nominal diameter: DN50mm～DN500mm(NPS2～20)；
Nominal pressure: PN1.6MPa～42MPa(ANSI CLASS150～2500)；
Operating temperature: -29℃-450℃.
APLICATION:
The valve is widely applied as a medium distribution, confluence or flow direction switching device in pipelines of coal chemical,
petrochemical, rubber, paper making, pharmaceutical and other industries.
Specification
item
value
Warranty
1 YEAR
Certification
pcoc
Customized support
OEM
Place of Origin
China
Brand Name
Chuanyi
Model Number
Tee Hard-seal Ball Valve
Product Name
3 ways valve control valve with good price Tee Hard-seal Ball Valve
Material
Alloy/stainless steel
Model
Tee Hard-seal Ball Valve
Brand
Chuanyi
Nominal diameter
DN50mm~DN500mm(NPS2~20)
Nominal pressure
PN1.6MPa~42MPa(ANSI CLASS150~2500)
Operating temperature
-29℃-450℃
Colour
blue and white
Body Materials
steel
Type
valve
The AMS Trex Device Communicator expands the long line of Emerson handheld devices while adding new capabilities that adapt it to consumer expectations for mobile device functionality. Technicians armed with a Trex communicator won’t waste time bringing devices back to the shop for analysis or reconfiguration. AMS Trex is delivered with a complete, pre-installed DD library for over2,000 HART and FOUNDATION Fieldbus devices so users can easily diagnose device problems in the field. Simple issues can bead dressed on the spot, avoiding unnecessary, and potentially destructive, invasive physical investigation of the problem.Technicians need powerful and portable diagnostic tools so they can identify and troubleshoot device issues to minimize processupsets. With a Trex communicator in hand, you can properly diagnose device issues in the field. With the right handheld,maintenance teams will experience significant savings in work hours and peace of mind knowing that problems will be fixed quickly and properly the first time. Once changes are made in the field, AMS Trex will automatically synchronize the information with the AMS Device Manager database via Wi-Fi or USB connection
