Product Description:
The Fisher FIELDVUE DVC6200 instrument is a state-of-the-art solution that significantly improves operational performance. With its precise control capabilities and continuous monitoring system, this device ensures that your system stays as close as possible to the setpoint, resulting in improved product quality.
The device comes equipped with an innovative diagnostic technology called FIELDVUE Performance Diagnostics. This unique feature makes it possible for the device to monitor the valve operation in real-time, providing detailed insights into its performance and reliability. With this information, proactive measures can be taken to maintain optimal valve functionality, which reduces downtime and boosts operational efficiency.
The diagnostic capabilities of the FIELDVUE DVC6200 also provide users with unparalleled control, allowing for precise adjustment of the valve to meet specific process requirements. This level of control helps reduce variability, leading to more consistent product quality and improved plant efficiency.
Features:
Improved Control System
The DVC6200 is an advanced valve controller that has been designed to provide improved performance and reliability. The high-performance linkage-less feedback system eliminates physical contact, which means that the valve is less likely to wear out. This leads to a longer lifespan for the valve and significantly reduces maintenance costs.
Furthermore, the DVC6200 features fully encapsulated electronics that are resistant to the effects of vibration, temperature, and corrosive atmospheres. This means that it can operate safely in a wide range of environments and is highly resistant to damage caused by environmental factors.
Another significant advantage of the DVC6200 is that it provides quick responsiveness to large step changes and precise control for small setpoint changes. This ensures that the valve operates smoothly and efficiently, and that any changes in the setpoint can be quickly and accurately applied.
The DVC6200 is also a HART communicating device, which means that information can be accessed anywhere along the loop. This flexibility allows for greater control over the valve, reduces exposure to hazardous environments, and makes it easier to evaluate valves in hard to reach locations.
In addition, the modular design of the DVC6200 allows critical working components to be replaced without removing field wiring or pneumatic tubing. This ensures that maintenance is quick and easy, and that the valve can continue to operate reliably even in the event of a failure.
Finally, when installed in an integrated control system, the DVC6200 can achieve significant hardware and installation cost savings. It also features self-diagnostic capability, which provides valve performance and health evaluation, and digital communication that provides easy access to the condition of the valve.
Technical Parameters:
| Technical Parameter |
Description |
| Valve Position Regulator Type |
Digital Valve Positioner |
| Operating Temperature |
Standard Temperature, High Temperature |
| Max Outlet Pressure |
145 Psig |
| Power Source |
Local |
| Shell Material |
Industrial Aluminum Housing |
| Supply Media |
Air, Natural Gas, Nitrogen |
| Area Classification |
Explosion Proof, Intrinsically Safe, FISCO, Type N, Flame Proof, Non-incendive For FM |
| Warranty |
1 Year |
| Data Interface |
Wired |
| Communication Protocol |
HART, 4-20mA Analog |
Applications:
The Fisher DVC6200 digital valve positioner has become a highly successful and widely used device across various industries. It is particularly prevalent in fluid control and regulation within liquid and gas pipeline systems in industrial production.
Furthermore, the DVC6200 plays a crucial role in raw material flow control and production stability in the chemical industry. This device is an essential tool in ensuring smooth and safe production processes. Additionally, in the oil and gas sector, the DVC6200 also regulates pipeline flow and pressure, which significantly contributes to the overall efficiency of extraction and transportation operations.
Its versatility and reliability make it an essential tool in optimizing production across multiple sectors. Whether in an industrial, chemical, or oil and gas field, the Fisher DVC6200 digital valve positioner is the go-to for precise, efficient, and reliable fluid control and regulation.
Support and Services:
The Control Valve Positioner product provides the following technical support and services:
- Installation and commissioning support
- Product training and education
- Maintenance and repair services
- Remote diagnostic and troubleshooting assistance
- Product upgrades and retrofits
Packing and Shipping:
Product Packaging:
The control valve positioner will be carefully packed in a sturdy cardboard box with cushioning material to prevent damage during transport. The box will be clearly labeled with the product name, model number, and any other relevant information.
Shipping:
The control valve positioner will be shipped via a trusted and reliable courier service. The estimated delivery time will depend on the destination, but customers can expect the product to arrive within 3-7 business days. Shipping fees will be calculated based on the delivery address and will be added to the final invoice.
