Azbil Valve is composed of several key components, including the valve body, valve plate, valve stem, bearing, seal, and more.
The valve body is considered the core of the entire valve. This crucial component is responsible for being connected to the pipeline and controlling the flow of the fluid.
The valve plate is a critical part of the valve that is utilized to open or close the valve port, allowing or preventing the flow of fluid through the pipeline.
The valve stem is what interconnects the valve plate and the operating mechanism. This crucial component allows the system to open and close the valve as needed.
Bearings play an essential role in supporting the valve plate and stem components, providing stability and crucial support for the seal and other components.
The seal is an important component that prevents fluid leakage through the valve. This vital component ensures that the valve functions efficiently and that all the components work together seamlessly.
The valve design of AZBIL conforms to explosion-proof standards, ensuring its explosion-proof performance. It can be used safely in an explosive environment, preventing any explosions that may be caused by electrical sparks or high temperature.
The valve boasts high-precision detection ability, which accurately detects the valve opening and closing state. This feature ensures accurate control of the valve.
The shell of the valve is made of aluminum alloy casting, and after anti-rust treatment and baking paint, has good corrosion resistance. This makes it suitable for use in all kinds of harsh environments.
The valve is built with a strong aluminum die-casting case and a two-circuit double-break basic switch, making it not easy to damage. It also reliably cuts off the circuit.
The compact design of the valve allows for easy installation, making it suitable for a variety of space-limited installation environments.
The valve comes in various specifications, including carbon steel, Cr-Mo steel, stainless steel, etc. This allows for the valve to be used with different fluids and control needs.
The valve has an equivalent to NEMA4X, IP65 drip-proof structure, which makes it suitable for use in all kinds of environments.
The valve has a built-in thermal protector to prevent motor burning, as well as a feedback mechanism that provides 4-20mA analog standard signal, contact signal, and resistance output feedback.
| Valve Type: | Control Valve |
| Product Name: | Chinese Pneumatic Control Valve |
| Nominal Diameter: | DN15~DN600 |
| Nominal Pressure: | PN1.6~42MPa ANSI 150~2500LB |
| Temperature Range: | -196 To 400°C |
| Control Signal: | 4-20 MA |
| Lining: | PFA, Translucent, Melt Processed |
| Basic Error: | ±1% |
| Connections: | Flanged |
| Application: | Low Emission Gland Packing |
| Warranty Period: | 1 Year |
| Brand: | Azbil |
AZBIL valves have a wide range of applications in various industries across the world. These valves are extensively used in the petrochemical industry to regulate the flow and pressure of fluids and gases.
The coal chemical industry also benefits from AZBIL valves as they play a significant role in gas treatment and transmission. These valves help in ensuring the efficient operations of gas pipelines and refineries, enhancing productivity levels.
The electric power industry is another essential sector that relies on AZBIL valves. These valves aid in maintaining the stable operations of power generation and transmission systems. By regulating fluid flow and pressure, these valves contribute significantly to keeping the power grid functional.
AZBIL valves also have other miscellaneous applications in various industries, including air conditioning systems, water treatment plants, and more. With their versatility and reliability, these valves have become popular among engineers across multiple disciplines.
The Pneumatic Control Valve product is designed to provide reliable and accurate control of fluid flow in a variety of applications. Our technical support team is available to assist with any questions or issues related to the installation, operation, and maintenance of the valve.
Our services include:
Our experienced technicians and engineers are dedicated to providing the highest level of service and support to ensure your Pneumatic Control Valve operates at peak performance and meets your specific application needs.
