Azbil valve is comprised of several integral components that function together to control fluid flow. These components include:
The valve body is considered the main component of the valve and is responsible for controlling the flow of fluid. It is connected to the pipeline in order to facilitate this control.
A valve plate is another key part of the valve and is utilized to open or close the valve port. The valve stem serves as the connection point between the valve plate and the operating mechanism.
Bearings are important components that support the valve plate and stem. Finally, a seal serves to create a tight seal at the valve port, thereby preventing fluid leakage.
The AZBIL valve design conforms to explosion-proof standards, ensuring safe usage in explosive environments. This helps prevent explosions caused by electrical sparks or high temperatures.
The AZBIL valve has high-precision detection ability, which enables it to accurately detect the valve's opening and closing state. This ensures precise control in any given situation.
The AZBIL valve's shell is made of aluminum alloy casting and undergoes anti-rust treatment and baking paint. This results in good corrosion resistance, suitable for use in various harsh environments.
The AZBIL valve uses a strong aluminum die-casting case and is built-in with two circuit double break basic switches. This ensures the valve is not easily damaged and can reliably cut off the circuit.
The AZBIL valve has a compact design that makes it easy to install. It is suitable for a variety of space-limited installation environments.
AZBIL valves are available in a wide range of materials and specifications, including carbon steel, Cr-Mo steel, stainless steel, etc. This makes it suitable for different fluids and control needs.
The AZBIL valve has an equivalent to NEMA4X, IP65 drip-proof structure. This makes it suitable for all kinds of environments.
The AZBIL valve has a built-in thermal protector to prevent motor burning.
AZBIL valves provide 4-20mA analog standard signal, contact signal, resistance output feedback. This helps provide the user with vital information about the valve's performance.
| Technical Parameter | Value |
|---|---|
| Temperature Range | -196 to 400°C |
| Valve Type | Control Valve |
| Basic Error | ±1% |
| Warranty Period | 1 Year |
| Connection Type | Flange Type, Internal Thread, Welded |
| Nominal Diameter | DN15~DN600 |
| Connections | Flanged |
| Nominal Pressure | PN1.6~42MPa ANSI 150~2500LB |
| Application | Low Emission Gland Packing |
| Inherent Characteristics | Linear |
AZBIL valves are highly popular in many different industrial sectors. These sectors are not limited to, but include:
The Pneumatic Control Valve product comes with technical support and services to ensure proper installation, operation, and maintenance. Our team of experts can assist with troubleshooting, repairs, and replacements. We also offer training and education on the product to improve understanding and proficiency. Our services include calibration, testing, and certification to ensure optimal performance and compliance with industry standards. Additionally, we provide documentation and manuals for reference and guidance. Contact us for more information on how we can support your Pneumatic Control Valve product needs.
