Steam traps are an essential component of the steam and condensate water system. They play a crucial role in preventing steam leakage and efficiently discharging condensate water and non-condensable gases when necessary. This process optimizes the utilization of thermal energy and helps in averting water hammer incidents.
Steam traps are required to withstand erosion, corrosion, and dirt. It is important to note that a single type of steam trap may not be suitable for all operational conditions due to the diverse nature of applications.
The users of steam traps come from various industries ranging from small laundries to large-scale petrochemical plants and other sectors such as papermaking, textiles, metallurgy, feed, food and beverages, hotels, and hospitals. The wide spectrum of users has led to the development of different types of steam traps in the market, each catering to specific needs and preferences of users.
High-pressure steam transportation
boasts excellent quality and high efficiency. In many cases, pressure reduction is required once steam is utilized to minimize equipment costs.
Low-pressure steam
holds a higher amount of latent heat energy, and its condensate water generates less flash steam. To regulate the system pressure of steam, self-powered pressure reducing valves or electric/pneumatic control valves are employed.
| Resolution | ≤ 0.25% |
| Flow Characteristic | Linear |
| Temperature Rating | 0-400°F |
| Actuator Area | 160 Cm² · 320 Cm² |
| Port | Main Ports In China |
| Optional Solenoid Valve | With |
| Maximum Current | 30 VDC Compliance Voltage |
| Voltage | 110V/220V |
| Mounting Position | Upright, Condensate Drainage Downwards |
| Inlet Pressure Rating | 210 Psi (15 Bar) |
Deep understanding and practical experience in steam systems are essential. It is crucial to master the application principles and modern technologies of steam products. By doing so, one can effectively deliver safe, efficient, and environmentally friendly solutions for steam and thermal energy systems to users.
Our Product Technical Support and Services for Pneumatic Control Valves include:
- Installation guidance and support
- Troubleshooting assistance
- Maintenance recommendations
- Repair services
- Product training and education
Product Packaging:
Our Pneumatic Control Valves are carefully packaged to ensure safe delivery. Each valve is wrapped in protective material to prevent any damage during transportation. Multiple valves are then placed in a sturdy cardboard box with ample cushioning to provide extra protection.
Shipping Information:
Once your order is placed, our team will process it promptly. We offer various shipping options to suit your needs, including standard and expedited delivery. You will receive a tracking number once your package is shipped, allowing you to monitor its journey to your doorstep.
