Original Endress Hauser PMC41 PMC51 PMC71 Ceramic Sensor E+H Gas Liquid Digital Pressure Transmitter for Pharmaceuticals Food

Product Introduction of Endress+Hauser PMC51 Pressure Transmitter

• High-Precision Measurement
  Standard accuracy of ±0.15%, with Platinum versions achieving ±0.055%, meeting stringent process control requirements. The ceramic sensor (99.9% Al₂O₃) offers strong overload resistance and stability in high-temperature (-40°C to +100°C) and high-pressure (100 mbar to 40 bar) environments.
• Intelligent Diagnostics & Remote Operation
  Integrated diagnostics monitor sensor status, temperature, and vibration in real-time, providing early fault warnings. Wireless access via the SmartBlue App enables parameter configuration, calibration, and data analysis, significantly reducing maintenance costs.
• Functional Safety & Certifications
  Compliant with IEC 61508 for SIL2 functional safety, ensuring reliability in critical processes. Explosion-proof certifications (ATEX, FM, CSA) and NACE MR0175 corrosion resistance make it suitable for hazardous areas and corrosive media.
• Flexible Communication & Interfaces
  Standard 4-20mA+HART with optional Profibus PA or FF Foundation Fieldbus, supporting Modbus TCP/IP (customizable). Modular design allows quick replacement of display units or electronics for adaptability.
• Hygienic Design
  Offers Tri-Clamp, DIN11851, and other hygienic process connections compliant with 3A and EHEDG certifications, ideal for food and pharmaceutical industries.

• Chemical & Petrochemical: Reactor pressure monitoring, pipeline flow regulation, with corrosion resistance ensuring long-term reliability.
• Food & Pharmaceutical: Hygienic connections and certifications meet CIP/SIP requirements for product safety.
• Energy & Power: Steam system pressure monitoring, high accuracy supports energy efficiency optimization.
• Water Treatment: Sewage network pressure management, IP67 protection resists moisture.
