Emerson Rosemount 3144P Field-mounted Temperature Transmitter with HART 7

1
MOQ
US $745.00 - 845.00/ Set
Price
Emerson Rosemount 3144P Field-mounted Temperature Transmitter with HART 7
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Rosemount 3144P Temperature Transmitter
Output Signal: 4-20 MA With HART 5/6/7
Housing Material: Aluminum, Stainless Steel
Protocol Support: HART, FOUNDATION Fieldbus, PROFIBUS PA (depending On Model Variant)
Ingress Protection: IP66/67, NEMA 4X
Power Supply: 12-42.4 VDC (10.5 VDC Minimum For Digital Only)
Sensor Input Channels: Single Or Dual Sensor Input
Highlight:

Field-mounted Temperature Transmitter

,

Rosemount 3144P Temperature Transmitter

,

HART 7 Temperature Transmitter
Basic Infomation
Place of Origin: China
Brand Name: Rosemount
Model Number: 3144P
Payment & Shipping Terms
Packaging Details: Carton + Wooden Box + Protection
Delivery Time: 90 working days
Payment Terms: T/T
Supply Ability: 1000 sets per year
Product Description
Emerson Rosemount 3144P Field-mounted Temperature Transmitter
Product Overview

The Rosemount 3144P is a field-mounted intelligent temperature transmitter optimized for electronic temperature measurement in industrial automation. It combines dual-input capability with smart diagnostics, ensuring reliable operation in challenging environments. Its compact design and multi-protocol support make it a versatile choice for process control.

Emerson Rosemount 3144P Field-mounted Temperature Transmitter with HART 7 0
Key Features
  • Intelligent Electronics: Built-in microprocessor for advanced signal processing
  • Field-Mounted Durability: IP66/NEMA 4X rating for outdoor use
  • Dual Input Redundancy: Supports two sensors for backup or differential measurement
  • Easy Configuration: Local LCD interface with push-button navigation
  • Global Safety Standards: SIL 2/3 certification for functional safety
  • Low Power Consumption: 1.2W typical power usage
Technical Specifications
Attribute Value
Product name Rosemount 3144P Temperature Transmitter
Output Signal 4-20 mA with HART 5/6/7
Housing Material Aluminum, stainless steel
Protocol Support HART, FOUNDATION Fieldbus, PROFIBUS PA (depending on model variant)
Ingress Protection IP66/67, NEMA 4X
Power Supply 12-42.4 VDC (10.5 VDC minimum for digital only)
Sensor Input Channels Single or Dual sensor input
Input Types RTD (Pt100), Thermocouples (J/K/T/E)
Accuracy ±0.1°C (RTD), ±0.25% (TC)
Communication HART 7, Foundation Fieldbus
Display Local LCD (4-digit)
Weight 450g
Mounting Field (DIN Rail or Bracket)
Safety Approvals ATEX, IECEx, SIL 2/3
Ambient Temperature -50°C to +85°C
Typical Applications
  • Metal heat treatment furnaces
  • Food processing pasteurization systems
  • Renewable energy (solar/geothermal) plants
  • Marine and offshore platform temperature control
