Rosemount 3144P Smart Temperature Transmitter 3051 3051S 3051L Intelligent Digital Pressure Transmitter
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Rosemount 3144P + 3051 Smart Transmitter Combo
Output Signal: 4-20 MA With HART 5/6/7
Operating Temperature: -40 To +85 °C Ambient, Sensor Dependent
Protocol Support: HART, FOUNDATION Fieldbus, PROFIBUS PA
3051 Pressure Types: Differential Pressure , Gauge Pressure , Absolute Pressure
3051 Power Supply: 10.5-42.4 VDC (depends On Output Protocol)
3144P Power Supply: 12-42.4 VCD
3051 Accuracy: Up To ±0.04% Of Span (3051S: ±0.025%)
3144P Accuracy: Up To ±0.014 °C For Pt100, Or ±0.01% Of Span
Explosion Proof: ATEX, IECEx, FM, CSA (Ex D, Ex Ia)
Highlight:

3051S Smart Temperature Transmitter

,

Rosemount 3144P Smart Transmitter

,

3051L Intelligent Digital Pressure Transmitter
Basic Infomation
Place of Origin: China
Brand Name: Rosemount
Model Number: 3144P+3051
Payment & Shipping Terms
Packaging Details: Carton + Wooden Case + Protection
Delivery Time: 90 working days
Payment Terms: T/T
Supply Ability: 1000 units per year
Product Description
Rosemount 3144P Smart Temperature Transmitter 3051 3051S 3051L Intelligent Digital Pressure Transmitter
Product Specifications
Attribute Value
Product Name Rosemount 3144P + 3051 Smart Transmitter Combo
Output Signal 4-20 mA with HART 5/6/7
Operating Temperature -40 to +85 °C ambient, sensor dependent
Protocol Support HART, FOUNDATION Fieldbus, PROFIBUS PA
3051 Pressure Types Differential Pressure, Gauge Pressure, Absolute Pressure
3051 Power Supply 10.5-42.4 VDC (depends on output protocol)
3144P Power Supply 12-42.4 VCD
3051 Accuracy Up to ±0.04% of span (3051S: ±0.025%)
3144P Accuracy Up to ±0.014 °C for Pt100, or ±0.01% of span
Explosion Proof ATEX, IECEx, FM, CSA (Ex d, Ex ia)
Temperature & Pressure Measurement Solution: Rosemount 3144P + 3051 Series
Product Overview

The Rosemount 3144P Smart Temperature Transmitter and 3051 Series Intelligent Digital Pressure Transmitter form a cost-effective, high-precision industrial measurement solution. Designed for oil & gas, chemical, and power industries, this combination provides synchronized temperature and pressure data acquisition, supporting HART and Foundation Fieldbus protocols for seamless integration into control systems.

Key Features

Rosemount 3144P Temperature Transmitter:

  • Dual sensor input for redundancy or differential measurement
  • ±0.1°C accuracy (RTD) with advanced diagnostics
  • IP66/NEMA 4X field-mounted design

Rosemount 3051 Series Pressure Transmitter:

  • High accuracy (±0.075%) with digital output
  • Supports 3051S (standard), 3051L (low-flow), and 3051T (differential) models
  • SIL 2/3 certified for functional safety

Combined Advantages:

  • Unified communication via HART/Fieldbus
  • Reduced installation costs with shared power supply
  • Real-time data synchronization for process optimization
Technical Parameters

Rosemount 3144P Temperature Transmitter

Parameter Value
Model 3144P
Input Types RTD (Pt100), Thermocouples
Accuracy ±0.1°C (RTD), ±0.25% (TC)
Communication HART 7, Foundation Fieldbus
Operating Temperature -50°C to +85°C
Rosemount 3144P Smart Temperature Transmitter 3051 3051S 3051L Intelligent Digital Pressure Transmitter 0

Rosemount 3051 Series Pressure Transmitter

Parameter Value
Model 3051S/3051L/3051T
Measurement Range 0.1 inH₂O to 40,000 psi
Accuracy ±0.075% (Gauge/Absolute)
Communication HART 7, PROFIBUS PA
Power Supply 12-36V DC
Rosemount 3144P Smart Temperature Transmitter 3051 3051S 3051L Intelligent Digital Pressure Transmitter 1
Applications
  • Oil & gas wellhead pressure/temperature monitoring
  • Chemical reactor multi-parameter control
  • Power plant boiler steam flow optimization
  • Refrigeration system efficiency analysis
