Home /Products/Industrial Instruments/Supplier Rosemount 3144P 3051 Industrial Digital Temperature and Pressure Measurement Transmitter HART Oil and Gas

Supplier Rosemount 3144P 3051 Industrial Digital Temperature and Pressure Measurement Transmitter HART Oil and Gas

1
MOQ
US $1550.00 - 2650.00/ Set
Price
Supplier Rosemount 3144P 3051 Industrial Digital Temperature and Pressure Measurement Transmitter HART Oil and Gas
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Rosemount 3144P + 3051 Smart Transmitter Combo
Output Signal: 4-20 MA With HART 5/6/7
Operating Temperature: -40 To +85 °C Ambient, Sensor Dependent
Protocol Support: HART, FOUNDATION Fieldbus, PROFIBUS PA
3051 Pressure Types: Differential Pressure , Gauge Pressure , Absolute Pressure
3051 Power Supply: 10.5-42.4 VDC (depends On Output Protocol)
3144P Power Supply: 12-42.4 VCD
3051 Accuracy: Up To ±0.04% Of Span (3051S: ±0.025%)
3144P Accuracy: Up To ±0.014 °C For Pt100, Or ±0.01% Of Span
Explosion Proof: ATEX, IECEx, FM, CSA (Ex D, Ex Ia)
Highlight:

Industrial Pressure Measurement Transmitter

,

Temperature Pressure Measurement Transmitter

,

HART Pressure Measurement Transmitter
Basic Infomation
Place of Origin: China
Brand Name: Rosemount
Model Number: 3144P+3051
Payment & Shipping Terms
Packaging Details: Carton + Wooden Case + Protection
Delivery Time: 90 working days
Payment Terms: T/T
Supply Ability: 1000 units per year
Product Description
Rosemount 3144P + 3051 Smart Transmitter Combo
Emerson's Rosemount 3144P + 3051 Series bundle provides simultaneous temperature and pressure measurement for oil & gas applications. This HART-compatible solution features smart diagnostics, rugged construction, and SIL safety certifications for reliable operation in harsh environments.
Product Specifications
Attribute Value
Output Signal 4-20 mA with HART 5/6/7
Operating Temperature -40 to +85 °C ambient, sensor dependent
Protocol Support HART, FOUNDATION Fieldbus, PROFIBUS PA
3051 Pressure Types Differential Pressure, Gauge Pressure, Absolute Pressure
3051 Power Supply 10.5-42.4 VDC (depends on output protocol)
3144P Power Supply 12-42.4 VCD
3051 Accuracy Up to ±0.04% of span (3051S: ±0.025%)
3144P Accuracy Up to ±0.014 °C for Pt100, or ±0.01% of span
Explosion Proof ATEX, IECEx, FM, CSA (Ex d, Ex ia)
Key Features
Integrated Benefits
  • Dual-parameter monitoring (temperature/pressure) via single platform
  • Reduced cabling and installation complexity
  • Remote configuration via HART handheld or DCS
Rosemount 3144P
  • Wet steam detection (optional)
  • Local LCD display with push-button setup
Rosemount 3051 Series
  • Explosion-proof (ATEX/IECEx) for hazardous areas
  • Low power consumption (1.2W)
Technical Parameters
Rosemount 3144P Temperature Transmitter
Parameter Value
Safety Certifications ATEX, IECEx, SIL 2/3
Housing Material 316L Stainless Steel
Rosemount 3051 Series Pressure Transmitter
Parameter Value
Pressure Types Gauge, Absolute, Differential
Temperature Range -40°C to +125°C (electronics)
Typical Applications
  • Offshore platform well testing
  • Natural gas pipeline custody transfer
  • Petrochemical distillation column control
  • LNG terminal storage tank monitoring
Tag:

Liquid level measurement Oil storage tank

80GHz radar level transmitter instrument

Industrial Pressure Measurement Transmitter
