Home /Products/Industrial Instruments/Endress+Hauser Proline Promag 50P 53P Electromagnetic Flowmeter DN15-DN600

Endress+Hauser Proline Promag 50P 53P Electromagnetic Flowmeter DN15-DN600

1
MOQ
4000USD~10000USD
Price
Endress+Hauser Proline Promag 50P 53P Electromagnetic Flowmeter DN15-DN600
Features Gallery Product Description Request A Quote
Features
Specifications
Measuring Principle: Electromagnetic
Output Signal: 4–20 MA, HART, Modbus, Profibus, EtherNet/IP
Special Features: Heartbeat Technology, Touch Control, Backlit Display
Ingress Protection: IP66/67 (standard), IP68 (optional)
Maximum Pressure: PN 40 / Class 300
Electrode Material: 316L / Hastelloy / Tantalum / Platinum / Titanium
Nominal Diameter: DN15–DN600 (½″–24″)
Power Supply: AC 100–230 V / DC 24 V
Highlight:

Proline Promag 50P electromagnetic flowmeter

,

Promag 53P industrial flowmeter

,

DN15-DN600 electromagnetic flow sensor
Basic Infomation
Brand Name: Endress Hauser
Certification: QC
Model Number: Promag Series
Document: xiangjing valve&instrument ...t .pdf
Payment & Shipping Terms
Packaging Details: Wooden Box/Carton Box
Delivery Time: 8-10weeks
Payment Terms: EXW
Supply Ability: 300PCS/Month
Product Description
Original E+H Endress+Hauser Proline Promag 50P, 53P Electromagnetic Flowmeter
Key Features
  • Measuring Principle: Electromagnetic
  • Output Signals: 4–20 MA, HART, Modbus, Profibus, EtherNet/IP
  • Advanced Features: Heartbeat Technology, Touch Control, Backlit Display
  • Robust Protection: IP66/67 (standard), IP68 (optional)
  • High Pressure Rating: PN 40 / Class 300
  • Material Options: 316L / Hastelloy / Tantalum / Platinum / Titanium electrodes
Technical Specifications
Parameter Specification
Nominal Diameter DN15–DN600 (½″–24″)
Measuring Principle Electromagnetic
Maximum Pressure PN 40 / Class 300
Accuracy ±0.5% ±1 mm/s (optional: ±0.2%)
Ingress Protection IP66/67 (standard), IP68 (optional)
Liner Material PTFE / PFA
Electrode Material 316L / Hastelloy / Tantalum / Platinum / Titanium
Power Supply AC 100–230 V / DC 24 V
Medium Temperature Up to +180°C (PFA Liner)
Product Overview
The Proline Promag series from Endress+Hauser represents cutting-edge electromagnetic flow measurement technology for industrial applications. Designed for precision and reliability, these flowmeters meet stringent requirements with certifications including ATEX, IECEx, CSA, FDA, and EHEDG for hazardous environments.
Featuring PTFE/PFA liners for excellent chemical resistance and low friction, these instruments deliver accurate flow measurements even in challenging conditions. The electromagnetic measuring principle ensures high precision across a wide range of pipe sizes from DN15 to DN600 (½″ to 24″).
Applications
The Promag series is ideal for diverse industrial applications including:
  • Process water and wastewater treatment
  • Chemical processing and dosing systems
  • Food and beverage production
  • Pharmaceutical manufacturing
  • Oil and gas applications
With flexible power options (AC 100–230 V or DC 24 V) and multiple communication protocols, these flowmeters integrate seamlessly into existing control systems. The Swiss-engineered quality and innovative features like Heartbeat Technology ensure reliable performance and simplified maintenance.
