The Fisher FIELDVUE DVC6200 Digital Valve Controller is a robust, microprocessor-based valve positioner designed for single-acting and double-acting pneumatic actuators. Engineered by Emerson, the DVC6200 delivers exceptional control accuracy, extended service life, and seamless integration into HART-enabled process control systems.
The modular, field-replaceable design ensures long-term reliability and reduces downtime, making it ideal for harsh process environments.
Model | Fisher FIELDVUE DVC6200 |
Type | Digital Valve Controller |
Actuator Type | Single-acting or double-acting pneumatic |
Communication Protocol | HART |
Input Signal | 4-20 mA with HART |
Supply Pressure | 1.4 to 6 bar (20 to 90 psi) |
Air Consumption | Low, energy efficient |
Position Feedback | Digital and analog options |
Protection Rating | IP66 / NEMA 4X |
Operating Temperature | -40°C to +85°C |
Mounting | Linear or rotary actuators |
Certifications | ATEX, IECEx, FM (depending on model) |
For inquiries about the Fisher FIELDVUE DVC6200 Digital Valve Controller or compatible accessories, we offer fast delivery, competitive prices, and full technical support.
