Foxboro IDP10 I/A Series Electronic Differential Pressure Transmitters 4-20mA HART

The Foxboro IDP10 I/A Series Electronic Differential Pressure Transmitter is a high-accuracy industrial DP transmitter designed for differential pressure, liquid level, and flow measurement across a wide range of process applications.It uses a silicon strain-gauge microsensor to provide fast, stable, and repeatable measurement for chemical plants, oil and gas operations, power generation, and water treatment facilities.

The IDP10 supports analog 4–20 mA and optional digital communication such as HART and FoxCom, enabling remote configuration, diagnostics, and integration into modern control systems.

Its rugged NEMA 4X / IP66 housing, multiple sensor material options (316L, Hastelloy, Monel, Tantalum), and hazardous-area certifications make it suitable for harsh industrial environments.

• High-accuracy differential pressure measurement using proven silicon strain-gauge technology
• Stable long-term signal performance with low drift
• Available with HART, FoxCom, or 4–20 mA analog output for flexible system integration
• Wide range of pressure spans for low and high DP applications
• Multiple wetted materials including stainless steel, Hastelloy, Monel, and Tantalum
• Rugged enclosure options: epoxy-coated aluminum or 316 stainless steel
• Ingress protection: NEMA 4X and IEC IP66 for outdoor and corrosive environments
• Available in traditional and low-profile housing designs
• Configurable damping, square-root extraction, and failsafe behavior
• Optional LCD indicator for local display and configuration
• Hazardous-area certifications including ATEX, IECEx, FM, CSA

• Flow measurement using differential pressure across primary elements such as orifice plates, Venturi tubes, and nozzles
• Liquid level measurement in pressurized or sealed tanks
• Density or interface measurement in multi-phase process vessels
• Pipeline differential pressure monitoring
• Filter monitoring and pump control
• General process measurement in chemical, oil and gas, power, water, and industrial plants

• Provides accurate, repeatable measurement to improve process control
• Reduces maintenance with proven stable silicon sensor design
• Supports modern control system integration with HART/FoxCom diagnostics
• Suitable for corrosive, hazardous, or outdoor environments
• Flexible mounting and configuration for diverse applications
• Long product life and industrial-grade reliability

The Foxboro IDP10 measures the pressure difference between its high-pressure and low-pressure ports.This differential force causes slight deformation of the internal silicon sensor.The sensor converts the deformation into an electrical signal, which is linearized, temperature-compensated, and transmitted as a 4–20 mA or digital signal to the control system.

For flow measurement, the transmitter can output a square-root scaled signal corresponding to flow rate.

• Mount directly to a manifold or process connection
• Ensure proper orientation for liquid, gas, or steam service
• Connect loop wiring and grounding per installation manual
• Configure zero, span, damping, and failsafe modes
• Verify output using a test meter or HART communicator
• Optional: enable square-root extraction for flow measurement

What does the Foxboro IDP10 measure

It measures differential pressure, which can also represent flow or liquid level.

Does the IDP10 support HART

Yes. HART communication is available for remote configuration and diagnostics.

Can it be used in hazardous locations

Yes. Versions are available with ATEX, IECEx, FM, and CSA approvals.

What materials are available for corrosive processes

Options include Hastelloy, Monel, and Tantalum for aggressive media.

Is square-root extraction available

Yes. It can be selected for flow measurement applications.
