Emerson Rosemount 1056 Online Industrial Water Analyzer Intelligent Four Wire Transmitter for Wastewater Treatment

1
MOQ
US $1970.00 - 2580.00/ Set
Price
Emerson Rosemount 1056 Online Industrial Water Analyzer Intelligent Four Wire Transmitter for Wastewater Treatment
Features Gallery Product Description Request A Quote
Features
Specifications
Dimensions: 100.5*108.5*69.7mm
Digital Communication: HART Protocol (standard), Profibus DP (optional)
Ambient Operating Temperature: -20 °C To +55 °C (-4 °F To +131 °F)
Accuracy: ±0.01 PH, ±0.05% Of Range For Conductivity
Power Supply: 100-230 V AC ±10%, 50/60 Hz, Or 24 V DC
Basic Infomation
Brand Name: Rosemount
Model Number: 1056
Payment & Shipping Terms
Packaging Details: Cardboard box
Delivery Time: 60 days
Payment Terms: T/T
Supply Ability: 500 sets per year
Product Description

Rosemount 1056 Dual-Input Analyzer

The multi-parameter transmitter that's common in water treatment and process plants

Product Overview

The Rosemount 1056 is a dual-input analyzer that measures parameters like pH/ORP, conductivity, dissolved oxygen, chlorine, and turbidity. It accepts two sensors at once, shows readings on a large display, and sends 4–20 mA outputs. Plants use it for monitoring water quality because it's straightforward, handles multiple measurements in one box, and works with many Rosemount sensors.

Main Features

  • Large backlit LCD display
  • Dual sensor inputs
  • Multiple 4–20 mA outputs
  • HART communication option
  • Simple menu navigation
  • Alarm relays
  • Wall or pipe mount

Technical Specifications

Inputs Two sensor inputs
Parameters pH/ORP, contacting conductivity, toroidal conductivity, dissolved oxygen, chlorine, ozone, turbidity
Outputs 4–20 mA (up to three)
Display Large LCD with backlight
Power 85–265 VAC or 24 VDC
Enclosure NEMA 4X/IP66

Applications

  • Water and wastewater treatment
  • Power plant water monitoring
  • Food and beverage process control
  • Pharmaceutical water systems

Frequently Asked Questions

Q: Can it measure two parameters at once?
A: Yes, two sensor inputs.

Q: Does it have HART?
A: Yes, optional.
