VYC 513 514 614 Direct Acting Pressure Reducing Valve with Stainless Steel Internals and Adjustable Outlet Pressure for Steam Gas Regulation

The VYC 513, 514 and 614 are direct-acting pressure reducing valves designed for steam, water, air and non-corrosive gases. The 513 is screwed, 514 is flanged, and 614 is a high-capacity or special version. They reduce high inlet pressure to a stable lower outlet pressure automatically. These valves are simple, reliable and commonly used in steam systems, compressed air lines and water supply where no external power is available.

• Direct-acting – no pilot or external control needed
• Adjustable outlet pressure with spring-loaded mechanism
• Stainless steel internals for corrosion resistance
• Balanced design for stable regulation
• In-line maintenance (removable cover)
• High flow capacity in 614 model
• Built-in strainer option in some versions

• Models: 513 (screwed), 514 (flanged), 614 (high-capacity)
• Sizes: DN15 to DN50 typical
• Inlet Pressure (max): Up to 40 bar g
• Outlet Pressure Range: Adjustable from 0.5 to 10 bar (model-dependent)
• Maximum Temperature: Up to 250 °C (steam)
• Body Material: Bronze or stainless steel
• Connections: Screwed BSP/NPT (513), flanged PN40 (514/614)
• Flow Coefficient: High in 614 version

• Steam line pressure reduction
• Compressed air supply regulation
• Water pressure control in piping
• Boiler feed and auxiliary systems
• General industrial pressure reduction
