High Quality Foxboro SRD960 Smart Valve Positioner with Shanghai Lanlin Pneumatic Control Valve

1
MOQ
2600 dollars
Price
High Quality Foxboro SRD960 Smart Valve Positioner with Shanghai Lanlin Pneumatic Control Valve
Features Gallery Product Description Ratings & Review Request A Quote
Features
Specifications
Ambient Air Temperature For Operation: -40…176 °F (-40…80 °C)
IP Degree Of Protection: IP66
Pneumatic Operation: Single Acting /Double Acting
Communication Port Protocol: HART, 4...20 MA Profibus FOUNDATION Fieldbus
Highlight:

Foxboro SRD960 smart valve positioner

,

Shanghai Lanlin pneumatic control valve

,

smart valve positioner with warranty
Basic Infomation
Place of Origin: China
Brand Name: Foxboro
Model Number: SRD960
Document: FD-QG-PO-001-EN-DE-FR.pdf
Payment & Shipping Terms
Packaging Details: Carton + Wooden crate + Protective packaging
Delivery Time: 60 days
Payment Terms: T/T
Supply Ability: 600 units per year
Product Description
Product Overview

The Foxboro SRD960 is an intelligent, universal digital valve positioner designed for precise control of pneumatic actuators in industrial process environments. It offers advanced communication capabilities (HART, PROFIBUS PA, FOUNDATION Fieldbus) and a local LCD display with push-button interface for easy configuration and operation. Built for reliability in harsh conditions, it supports both single- and double-acting actuators with excellent linearity and diagnostic features.

Key Features
  • Advanced Communication: HART 4-20 mA, PROFIBUS PA, or FOUNDATION Fieldbus options.
  • Easy Setup: Local keypad and LCD for quick autostart configuration (Endpoints, Standard, Enhanced, Smooth/Fast response).
  • Robust Design: IP66 / NEMA 4X enclosure, explosion-proof (Ex ia) versions available.
  • High Performance: Linearity < 0.4%, hysteresis max. 0.3%, stroke range 8–260 mm, operating angle 0–95°.
  • Diagnostics: Auto diagnostics, step response analysis, position/response histograms.
  • Flexible Mounting: Multiple adapter options (NAMUR, direct mounting) for linear and rotary actuators.
  • SIL 3 Safety Level: Suitable for safety-critical applications.
Technical Specifications
Parameter Specification
Input Pressure 1.4–6 bar (20–90 psi)
Maximum Pressure 6 bar (90 psi)
Stroke Range 8–260 mm
Operating Angle 0–95°
Linearity < 0.4% of travel span
Maximum Hysteresis 0.3%
Pneumatic Operation Single / Double acting
Protection Rating IP66, NEMA 4X
Ambient Temperature -40…80°C (-40…176°F)
Certifications ATEX, FM, CSA
Communication HART, PROFIBUS PA, FOUNDATION Fieldbus
Applications

Ideal for process industries including oil & gas, chemical, power generation, and water treatment. Perfect for control valves in both linear and rotary actuator setups requiring high accuracy, diagnostics, and digital integration.

Frequently Asked Questions
Q: How do I perform initial setup?
A: Use the local keys and LCD to select mounting type then run Autostart (recommended: Standard for most applications).
Q: What air quality is required?
A: Supply air must be free of oil, dust, and water per ISO 8573-1 Class 2 solid particles / Class 3 oil.
Q: Is it suitable for hazardous areas?
A: Yes, explosion-proof Ex ia versions are available.
