Flowserve Logix 1500 Digital Valve Positioner with HART Communication IP66/NEMA 4X Enclosure and 4–20 mA DC Input

1
MOQ
US $1780.00 - 2300.00/ Set
Price
Flowserve Logix 1500 Digital Valve Positioner with HART Communication IP66/NEMA 4X Enclosure and 4–20 mA DC Input
Features Gallery Product Description Ratings & Review Request A Quote
Features
Specifications
Input Signal: 4–20 MA DC
Communication: HART 7 (Optional)
Air Supply Pressure: Up To 60 Psi (4.1 Bar)
Operating Temperature: -40°C To +85°C
Protection Class: IP66 / NEMA 4X
Valve Type: Single-Acting Linear & Rotary Valves
Highlight:

Flowserve PMV D20 limit switch box

,

HART communicator valve controller

,

Logix 1500 digital positioner
Basic Infomation
Brand Name: Flowserve
Model Number: Logix 1500
Payment & Shipping Terms
Packaging Details: Cardboard box/Wooden crate
Delivery Time: 6~8 weeks
Payment Terms: T/T
Supply Ability: 2000 sets per year
Product Description

Product Overview

The Flowserve Logix 1500 is a digital electro-pneumatic positioner designed for reliable and accurate control of pneumatic actuators on linear and rotary valves. It offers HART communication and straightforward local configuration, making it a practical choice for general process control applications where cost-effectiveness and dependable performance are important.

Technical Specifications

Parameter Specification
Input Signal 4–20 mA DC
Communication HART
Supply Air Pressure 30–150 psig (2–10 bar)
Air Consumption Low steady state
Linearity < ±1.0% FS typical
Repeatability < 0.2% FS
Operating Temperature –40 °C to +80 °C
Enclosure Rating NEMA 4X / IP66
Housing Material Aluminum

Application Industry

  • Chemical processing
  • Petrochemical plants
  • Power generation auxiliary systems
  • General industrial automation
  • Water treatment facilities

Common Problems & Solutions

  • Problem: Contaminated instrument air → Solution: Install proper filter-regulator
  • Problem: Field calibration → Solution: Easy local push-button setup
  • Problem: Steady-state air usage → Solution: Optimized low consumption design

Replacement Models

  • Older Flowserve Logix series
  • Logix 3200MD / 3400MD (higher performance variants)

Why Buy From Us

  • Genuine Flowserve Logix 1500 with warranty
  • Competitive pricing
  • Local technical support for installation and calibration
  • Reliable spare parts availability

Stock & Delivery Time

  • Standard models: 6–10 weeks typical
  • Special configurations: 8–14 weeks

RFQ Form

Please provide:

  • Actuator type (linear or rotary) and travel
  • Supply air pressure available
  • Hazardous area classification
  • Quantity & target delivery date
