High Quality Valmet Me-sto Neles ND9000 ND9106HX8T ND9206HE8T Smart HART Control Valve Positioner

1
MOQ
2030 dollars
Price
High Quality Valmet Me-sto Neles ND9000 ND9106HX8T ND9206HE8T Smart HART Control Valve Positioner
Features Gallery Product Description Ratings & Review Request A Quote
Features
Specifications
Temperature Range: -40 ... +85 °C / -40 ... +185 °F, Standard Version
Temperature Range(arctic Version): -53 ... +85 °C / -63 +185 °F
Communication: HART, FOUNDATION Fieldbus, Profibus PA
Protection Class: IP66 / NEMA 4X Enclosure
Supply Power: Loop Powered, 4-20 MA
Highlight:

Valmet Me-sto ND9000 HART control valve positioner

,

Neles ND9106HX8T smart valve positioner

,

ND9206HE8T control valve positioner with warranty
Basic Infomation
Place of Origin: China
Brand Name: Valmet/Neles
Model Number: ND9106HX8T/ ND9206HE8T
Document: 7nd9071en.pdf
Payment & Shipping Terms
Packaging Details: Carton + Wooden crate + Protective packaging
Delivery Time: 60 days
Payment Terms: T/T
Supply Ability: 500 units per year
Product Description
Product Overview

The Neles™ ND9000™ is a top-class intelligent valve controller engineered to operate on all control valve actuators across every industry sector. It delivers exceptional end-product quality under all operating conditions through unique diagnostics and outstanding performance. Designed as a reliable, future-proof investment with lifetime support, the ND9000 combines robust hardware, advanced self-diagnostics, and open architecture for seamless integration into modern process control systems.

Key Features
  • Benchmark control performance on both rotary and linear valves
  • Reliable and robust design with IP66 / NEMA 4X enclosure
  • Easy commissioning via Local User Interface (LUI), DTM/EDD or DCS asset management tools
  • Safety: IEC 61508 compliant up to and including SIL 2 (TÜV)
  • Language selection: English, German, French
  • Local and remote operation with expandable architecture
  • Advanced diagnostics: self-diagnostics, online diagnostics, performance diagnostics, communication diagnostics, extended offline tests, Performance View and Online Valve Signature
  • Interchangeable communication options: HART 6/7, FOUNDATION fieldbus, Profibus PA
  • Options including limit switches, position transmitter (HART), full stainless-steel enclosure, remote mounting and arctic version (down to –53 °C / –64 °F)
  • Low energy and air consumption, optimized spares program and retrofit capability to existing Neles or third-party valves
Technical Specifications
Category Specification
Power Loop-powered (4–20 mA HART) or bus-powered (FOUNDATION fieldbus / Profibus PA)
Travel range Linear: 10–120 mm; Rotary: 45–95° (measurement range 110°)
Temperature range Standard: –40 °C to +85 °C; Arctic: –53 °C to +85 °C
Enclosure IP66 / NEMA 4X (aluminium or stainless steel options)
Supply pressure 1.4–8 bar (20–115 psi)
Air capacity (4 bar) Spool 2: 5.5 Nm³/h; Spool 3: 12 Nm³/h; Spool 6: 38 Nm³/h
Steady-state consumption < 0.6 Nm³/h (spools 2 & 3); < 1.0 Nm³/h (spool 6)
Dead band / Hysteresis ≤ 0.1 % / < 0.5 %
Communication HART 6/7, FOUNDATION fieldbus ITK 6.1.2, Profibus PA Profile 3.0
Approvals ATEX, IECEx, INMETRO, cCSAus, Japanese Ex-d (various Ex ia/ib/ic/d/nA/tb)
Applications

Process industries requiring precise valve control and predictive maintenance: oil & gas, chemical, petrochemical, power generation, pulp & paper, mining, and water treatment. Suitable for both continuous and on-off control on single- or double-acting actuators.

Frequently Asked Questions

Q: Can the ND9000 be mounted on third-party actuators?

A: Yes, extensive mounting kits are available for VDI/VDE 3845 and IEC 60534-6 standards.

Q: Does it support 1-point calibration while the valve is in process?

A: Yes, the 1-point calibration feature allows installation without disturbing the process.

Q: What diagnostics are available?

A: Full suite including Online Valve Signature, Performance View with recommended actions, trends, histograms and online alarms.
