FOUNDATION Fieldbus Digital Positioning for Double-Acting Pneumatic Control Valves

DVC6200F is a FOUNDATION Fieldbus digital valve positioner designed for pneumatic control valve applications. This Double-Acting configuration uses pneumatic output to control both sides of a double-acting actuator for accurate valve positioning.

The digital positioner communicates with the control system through FOUNDATION Fieldbus, allowing users to access configuration, operating status, valve and actuator information, and diagnostic functions through the fieldbus network.

For replacement projects, process automation upgrades and new valve packages, DVC6200F provides a practical digital positioning solution when FOUNDATION Fieldbus communication and double-acting actuator control are required.

Why DVC6200F?

FOUNDATION Fieldbus + Double-Acting Control

Choosing the correct valve positioner starts with the communication protocol and actuator configuration.

DVC6200F Double-Acting is designed for applications requiring:

• FOUNDATION Fieldbus communication
• Double-acting pneumatic actuator control
• Relay A for double-acting operation
• Digital valve positioning
• Linkage-less, non-contact position feedback
• Valve and actuator configuration access
• Digital diagnostics and operating status

Built for Fieldbus-Based Valve Control

Unlike a conventional 4–20 mA positioner, DVC6200F is designed around a FOUNDATION Fieldbus communication architecture.

This allows valve-related information to be integrated into the plant control system rather than relying only on a conventional analog control signal.

The result is a solution better suited to plants where digital communication, configuration and valve diagnostics are part of the control strategy.

Key Parameters & Configuration

以上参数均以产品资料中能够确认的配置为基础,没有为了填表增加未经确认的电气输入,电压,精度等参数.官方产品选型资料明确列出 DVC6200F + Double-Acting operation + Relay A；产品手册明确说明其使用 FOUNDATION Fieldbus.

Configuration Note:
DVC6200F configurations can vary according to control functions, actuator arrangement, mounting method, approvals and other selected options. Please provide the actuator and valve information before ordering so the configuration can be checked.

Typical Applications

Oil & Gas

For pneumatic control valves used in process control systems where FOUNDATION Fieldbus communication is required.

Petrochemical & Chemical Processing

Suitable for digital valve control and monitoring in process automation systems.

Power Generation

Applicable to pneumatic control valve applications integrated with FOUNDATION Fieldbus-based control systems.

Process Automation

For plants upgrading from conventional valve positioning to digital fieldbus-based valve control.

Valve Replacement Projects

Suitable when replacing an existing positioner on a compatible double-acting pneumatic actuator, subject to configuration and mounting compatibility.

Double-Acting Configuration

For a double-acting actuator, the positioner controls pneumatic pressure to both sides of the actuator.

DVC6200F Double-Acting uses Relay A for this configuration. The product selection documentation specifically identifies Relay A as the relay configuration for double-acting operation.

This makes the actuator configuration an important part of the purchasing decision.

Before ordering, we recommend confirming:

Positioner Model → FOUNDATION Fieldbus → Double-Acting → Relay Configuration → Actuator → Valve → Mounting

Need a Configuration Check?

Not Sure Which DVC6200F Configuration You Need?

Don't order by model number alone.

Send us any of the following information:

• Existing positioner model
• Positioner nameplate photo
• Valve model
• Actuator model
• Actuator manufacturer
• Double-acting actuator information
• Required mounting arrangement
• FOUNDATION Fieldbus requirements
• Quantity required

Our team can help check the DVC6200F configuration and compatibility before quotation.

Send Your Existing Model or Nameplate

Get a Configuration Check →

Request a Quote

DVC6200F Double-Acting — Request Pricing

Tell us your required quantity and application. If you already have an existing positioner or actuator, provide the model number or nameplate information for a faster configuration check.

Product: DVC6200F Double-Acting
Communication: FOUNDATION Fieldbus
