Stainless Steel Water Pressure Control Valve , Gulde 5100 Fisher Control Valve

Basic Information
Place of Origin: China
Brand Name: Fisher Gulde
Model Number: Fisher Gulde 5100
Minimum Order Quantity: 1 Set/Sets
Price: Negotiation
Packaging Details: Packing type: cardboard box/non-fumigation wooden box
Supply Ability: 100 Set/Sets per Month
Application: General Material: Stainless Steel
Temperature Of Media: High Temperature Pressure: Medium Pressure
Power: Pneumatic Media: Acid
Port Size: Standard Structure: Regulating
Standard Or Nonstandard: Standard Port: Main Ports In China
High Light:

self operated regulator

,

fisher relief valve

Product Description

Fisher Gulde 5100 Control Valve

The Gulde control valve is ideally suited for control of flow and temperature where mixing or diverting service is required. This valve uses a rugged cast bronze or CF8M stainless steel body with S31600 austenitic stainless steel trim for extended service life.



Specifications

Certifications PED, CUTR, ATEX, CRN
Critical Service General Service, Mixing
Flow Characteristics Linear
Material Bronze, Stainless
Operating Temperature Standard Temperature
Pressure Class Bronze: 400 psi at 150°F/250 psi at 400°F; Stainless: 720 psi at 150°F/515 psi at 400°F
Process Connection Type Threaded, Welded-on Flanges
Shutoff Class Class III (FCI 70-2)
Valve Size NPS 1/2, NPS 1, NPS 1-1/2, NPS 2
Valve Size Standard NPS
Other Configurations Contact your local Emerson business partner or sales office to learn about additional specifications or options for this product.



Features

Optional ENVIRO-SEAL™ packing system can be used to meet critical emission control requirements; suitable for use in light duty chemical service.
High quality type 316 austenitic stainless steel trim materials are available.
Superior dual plug and stem guiding provides increased stability during plug travel.
Multiple trim capacity reductions available to meet changing process requirements.
Epoxy powder coated actuator with stainless steel fasteners for corrosion resistance.
Multi-spring, field reversible actuator with reduced deadband, permits direct operation from remote signal devices.
Entire actuator and yoke can be removed from the valve assembly while maintaining packing integrity.
Fisher FIELDVUE™ digital valve controllers are available for remote calibration and diagnostics in facilities utilizing the PlantWeb architecture.
