E+H thermometers temperature measurement TM101 basic sensor instrument el measurement

Basic Information
Place of Origin: Germany
Brand Name: E+H
Certification: ce eac
Model Number: temperature measurement TM101
Minimum Order Quantity: 1
Packaging Details: cartons
Delivery Time: 15 days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 999 piece/month
Outer Diameter Protection Tube / Insert: 6,0mm Max. Immersion Length: Up To 1.000,0 Mm (39'')
Integration Head Transmitter: (4 ... 20 MA; HART) Response Time: T90 Around 17 S
Thermocouple Typ K: Up To 600 °C (1.112 °F) Operating Temperature Range: -50 °C ...200 °C (-58 °F ...392 °F)
High Light:

6.0mm Temperature Measurement Thermometer

,

HART Temperature Measurement Thermometer

,

IP68 Temperature Measurement Thermometer

E+H thermometers temperature measurement TM101 basic sensor instrument el measurement

Specification



Product Name E+H thermometers temperature measurement TM101 basic sensor instrument
Model iTHERM ModuLine TM101
Application temperature measurement
Outer diameter protection tube / Insert 6,0 mm
Characteristic Basic technologie metric style
Max. immersion length up to 1.000,0 mm (39'')
Integration head transmitter (4 ... 20 mA; HART)
Response time t90 around 17 s
Accuracy Class A acc. to IEC 60751 Class B acc. to IEC 60751
Thermocouple Typ K up to 600 °C (1.112 °F)
Operating temperature range -50 °C ...200 °C (-58 °F ...392 °F)
Insert Material 316L (1.4404) Alloy 600 (2.4816)


Detailed Images

E+H thermometers temperature measurement TM101 basic sensor instrument el measurement 0E+H thermometers temperature measurement TM101 basic sensor instrument E+H thermometers temperature measurement TM101 basic sensor instrument E+H thermometers temperature measurement TM101 basic sensor instrument E+H thermometers temperature measurement TM101 basic sensor instrument E+H thermometers temperature measurement TM101 basic sensor instrument E+H thermometers temperature measurement TM101 basic sensor instrument E+H thermometers temperature measurement TM101 basic sensor instrument

E+H thermometers temperature measurement TM101 basic sensor instrument
